Vuzix Shield
On sale · United States ·
The Vuzix Shield is safety glasses with a green waveguide over each eye at 640x480. Stereo 13 MP cameras and Snapdragon XR1, certified to ANSI Z87.1 and sold since April 2024.
Specifications
| Field | Value | How we know |
|---|---|---|
| Brand | OFFICIALVuzix | How we know: Vuzix Corporation |
| Category | OFFICIALAugmented reality | How we know: Vuzix Corporation |
| Form factor | OFFICIALGlasses frame | How we know: Vuzix Corporation |
| Status | OFFICIALOn sale | How we know: Vuzix Corporation |
| Maker country | OFFICIALUnited States | How we know: Vuzix Corporation |
| Release | OFFICIALApr 07, 2024 | How we know: Vuzix Corporation |
| Announcement | OFFICIALNov 10, 2021 | How we know: Vuzix Corporation |
| Display type | OFFICIALDual (binocular) see-through waveguide optics | How we know: Vuzix Corporation[1] |
| Display color | OFFICIALGreen, a single color | How we know: Vuzix Corporation |
| Resolution | OFFICIAL640x480 per eye | How we know: Vuzix Corporation[2] |
| Field of view | OFFICIAL30° | How we know: Vuzix Corporation |
| Brightness | OFFICIAL4100 nits | How we know: Vuzix Corporation |
| Image in both eyes | OFFICIALYes | How we know: Vuzix Corporation |
| Camera | OFFICIAL13 MP | How we know: Vuzix Corporation |
| Video | OFFICIAL4K@30fps | How we know: Vuzix Corporation[3] |
| Microphones | OFFICIAL2 | How we know: Vuzix Corporation |
| Speakers | OFFICIAL2 | How we know: Vuzix Corporation |
| Wi-Fi | OFFICIALWi-Fi 802.11 b/g/n/ac, 2.4/5GHz | How we know: Vuzix Corporation[4] |
| Bluetooth | OFFICIALBluetooth 5.0 BR/EDR/LE | How we know: Vuzix Corporation[5] |
| Chip | OFFICIALQualcomm Snapdragon XR1 | How we know: Vuzix Corporation[6] |
| Memory | OFFICIAL6144 MB | How we know: Vuzix Corporation |
| Storage | OFFICIAL64 GB | How we know: Vuzix Corporation |
| System | OFFICIALAndroid 11 | How we know: Vuzix Corporation[7] |
| Developer access | OFFICIALPublic SDK | How we know: Vuzix Corporation |
| Prescription lenses | OFFICIALYes | How we know: Vuzix Corporation |
| Battery | We have not checked | How we know: OPEN QUESTION |
| Claimed battery life | We have not checked | How we know: OPEN QUESTION |
| Weight | We have not checked | How we know: OPEN QUESTION |
| Water protection | We have not checked | How we know: OPEN QUESTION |
| Price | OFFICIAL$2,499.99 | How we know: Vuzix Corporation |
Notes
- 1.Display type. Dual (binocular) see-through waveguide optics, single-layer, each driven by its own micro-LED projector (1-micron pixel pitch) [OFFICIAL, Vuzix Shield product page/spec sheet + Vuzix Waveguide OEM datasheet]
- 2.Resolution. 640x480 per eye (640x480x2) [OFFICIAL, support.vuzix.com/docs/vuzix-shield and /docs/getting-to-know-the-vuzix-shield-1]
- 3.Video. Stereo dual auto-focus 13MP cameras, up to 4K@30fps video, integrated privacy LED, advanced optical reader with barcode scanner [OFFICIAL, Vuzix Shield spec sheet v5.0 5/24]
- 4.Wi-Fi. Wi-Fi 802.11 b/g/n/ac, 2.4/5GHz [OFFICIAL, Vuzix Shield spec sheet v5.0 5/24]
- 5.Bluetooth. Bluetooth 5.0 BR/EDR/LE [OFFICIAL, Vuzix Shield spec sheet v5.0 5/24]
- 6.Chip. Qualcomm Snapdragon XR1, 8-core CPU at 2.52GHz [OFFICIAL: 8-core running Android 11 per spec sheet v5.0 5/24; '8 Core 2.52Ghz Qualcomm XR1 processor' per support.vuzix.com/docs/vuzix-shield and /docs/getting-to-know-the-vuzix-shield-1]
- 7.System. Android 11 [OFFICIAL, support.vuzix.com/docs/vuzix-shield; earliest Jan-2022 spec sheet said Android 10, updated to Android 11 by the May-2024 sales sheet and current support docs]
US$2,499.99 at the online launch in April 2024, reported by MicroLED-Info. On 2026-09-06 the Vuzix page showed no price, only a call to contact sales. No price in CNY or BRL.
What we measured in the lab
We did not measure this device in the lab.
Our review
For
- Vuzix declares 640x480 per eye at 4,100 nits, double the 2,000 it declares for the Blade 2 and M400.
- Vuzix's own guide says building for it is as simple as building for any other Android device.
- VSight praised the waveguide optics and the stereo camera for remote industrial collaboration.
- Vuzix certifies it to ANSI Z87.1 and EN166/170, including with prescription inserts fitted.
- Vuzix declares two 13 MP autofocus cameras, 4K at 30 fps, a privacy LED and a barcode reader.
Against
- VSight and VR52 both criticised the display for being monochrome green and nothing else.
- VR52 called 2,499.99 dollars expensive, the design bulky, and put the lens inserts at 149.99 more.
- Vuzix publishes no weight, no battery capacity and no runtime figure for this model.
- By 6 September 2026 the store sat behind a login and the page offered only volume orders.
- HardwareZone said it needs enterprise software behind it before it earns its place at work.
The Shield puts an image in front of both eyes. Each side has its own micro-LED projector feeding a waveguide at 640x480 per eye, 30 degrees and 4,100 nits, on a Snapdragon XR1 with 6 GB of memory and 64 GB of storage under Android 11, plus two 13 MP cameras recording 4K at 30 fps and a barcode reader.
Writing software for it is straightforward. Vuzix's own guide says developing for the Shield is as simple as for any other Android device, on standard Android APIs; the spec sheet says voice control reaches third party integrators through the SDK, and no store gate or sideload restriction is documented.
The reviews split along one line. VSight praised the waveguide optics and the stereo camera, said the ordinary glasses shape encourages daily industrial use, but named the monochrome display as the limit and said the display switching mechanism can get in the way. VR52 liked the display, the titanium frame and the safety certifications while calling it expensive and somewhat bulky.
Three things should stop a buyer. The display is green and nothing else, and Vuzix publishes no weight, no battery capacity and no runtime; the 5.11 g in its documents is the waveguide part alone. Buying one is the hard part: the 2,499.99 dollar launch price came from MicroLED-Info in April 2024, while on 6 September 2026 the page showed only a contact sales button, behind a store login.
Verdict
Two green Micro-LED waveguides, 640x480 per eye at 4,100 nits, on a frame certified to ANSI Z87.1 and EN166/170. It launched at 2,499.99 dollars in April 2024; by 6 September 2026 Vuzix's page offered only volume orders behind a login. Plain Android to code for, and a fleet buy, not a single unit.
Images
Vuzix Corporation · vuzix.com
Vuzix Corporation · vuzix.com
Where it is used
Sources
- Vuzix Shield Spec Sheet (1-20-2022) · Vuzix Corporation · retrieved on Sep 05, 2026
- Vuzix Shield Sales Sheet (v5.0, 5/24) · Vuzix Corporation · retrieved on Sep 05, 2026
- Vuzix Shield (support overview) · Vuzix Corporation (support docs) · retrieved on Sep 05, 2026
- Vuzix Shield Development Getting Started Guide · Vuzix Corporation (support docs) · retrieved on Sep 05, 2026
- Vuzix Shield Smart Glasses (archived official product page) · Vuzix Corporation (via Wayback Machine, snapshot 2026-06-07) · retrieved on Sep 05, 2026
- Vuzix Commences Online Sales of Its MicroLED Binocular Waveguide Smart Safety Glasses · Vuzix Corporation (PR Newswire) · retrieved on Sep 05, 2026
- Vuzix Shield Smart Glasses Named as Honoree for Multiple CES 2022 Innovation Awards · Vuzix Corporation · retrieved on Sep 05, 2026
- Vuzix launches online sales of its microLED-powered Shield Smart Safety Glasses · MicroLED-Info · retrieved on Sep 05, 2026
- Navigating Industrial Efficiency: A Comparative Review of Smart Glasses · VSight · retrieved on Sep 05, 2026
- Vuzix Shield 评测：安全的企业级智能眼镜 · VR52 · retrieved on Sep 05, 2026
- Vuzix Corp (VUZI) (Q2 2026) Earnings Call Highlights · Yahoo Finance / GuruFocus · retrieved on Sep 05, 2026
- Getting to Know the Vuzix Shield · Vuzix Corporation (support docs) · retrieved on Sep 05, 2026
- Vuzix Shield are advanced smart glasses that actually look good and safety certified for enterprise · HardwareZone Singapore · retrieved on Sep 05, 2026
